FV-45GT4/T

Propeller Ventilating Fan (Air Volume:5420CMH)

  • Blade Size : 18" / 45cm
  • High Static Pressure
  • 3-dimensional S-shaped blade
  • Horizontal or vertical installation
Color: White
Price: HK$3,670



Feature

  • Blade Size : 18" / 45cm
  • Bell mount construction with distinctive wave shape blade
  • Durable powder coating
  • Thermal cut-off motor
  • Wide ambient temperature range from -10℃ to +50℃
  • Possible to install horizontally or vertically
  • Three-phase, reversible
  • Size(mm): 570(H) x 570(W) x 297(D)

Specifications

FV-45GT4/T
FV-45GT4/T
Voltage 380 ~ 440 Voltage (V)
Power 240 Wattage (W)
Frequency 50 hertz (Hz)
Fan Speed 1460 R.P.M.
Air Volume 5420 Cubic meters per hour (m3/h)
Noise Level 52 decibel (dB(A))
Weight 18.5 Kilogram (kg)
* The product is subject to the actual product. Photos and product shots are for reference only. The actual color and size may vary slightly from those shown.
* Product specifications are subject to change without prior notice.
