EMR4112G-HK

Smart Lock

Push pull series
5 door opening methods (Fingerprint, Password, IC card, Mechanical key and Mobile App)
Unlock by easy touch
Price included standard installation

Color: Grey

Price: HK$6,080

User Manual
Catalogue
Downloads:

Feature

Push pull series
5 door opening methods (Fingerprint, Password, IC card, Mechanical key and Mobile App)
C-grade lock cylinder
Semiconductor Fingerprint Sensor
Virtual password function to protect password security
With door bell
Multiple alarms for home security: low voltage alarm; anti-pry alarm; incorrect attempt alarm
Two years warranty service (Apply to installation by Shun Hing Electric Service Centre Ltd. only), offer are subject to terms and conditions.
For preliminary assessment, please forward the measurement of the thickness of the door, distance between the lock and the door edge, photo of the door frame, door front and door side to our Whatsapp within office hour:Send WhatsApp to 6117-7235

Specifications

	EMR4112G-HK

	EMR4112G-HK
Brand	Panasonic
Power Supply	Lithium Battery (7.4V)
Emergency Charging interface	USB Type-C
Size (L x W x D)	Front Panel (mm): 413.5 x 70 x 70.3 Rear Panel (mm): 413.5 x 70 x 68.3
Distance from center of the lock	70mm
Length of password	6-12 digits
Number of Fake PIN code	16 digits (include correct password)
Number of Administrator Users	9
Number of Normal Users	191
Number of Fingerprint	100 groups
Number of passwords	200 groups
Number of cards	200 groups

FAQ

🙋 Can Panasonic Smart Lock be installed to replace existing door locks?

Please measure the door thickness and the distance from the center of the lock to the door edge and take pictures (front and side view of the door lock) to the sales person or installation technician to decide whether it is suitable for installation. Or send the information to Whatsapp: 6117-7235 for preliminary assessment within office hour.

🙋 Self-assessment and additional charges on installation of Panasonic Smart Lock for current door

Door thickness 40-90mm
Distance from the center of the lock to the door edge 60 or 70mm (If more than 70mm, likes 100 or 120mm, need to add front and rear steel plates around $600)
Distance between the metal gate and the door minimum required 80mm
The original size of slide faceplate is (L) 240mm x (W) 24mm, any other size will require around $200 surcharge

*If door lock area has metal surface, need to charge additional processing fee around $400.

*All the above additional charges are for reference only, subject to the quoted price of Shun Hing Installation technician.

Diagram on indicator definition and measurement guideline

🙋 Standard Installation and extra charge

Standard installation apply with wooden door only, $400 surcharge will apply with iron gate. Other extra service charge will be collected by technician during on-site.

🙋 What should I do if the power supply is almost out of power?

If the power supply is about to run out, there will be voice and mobile phone application prompts. Please re-charge the lithium battery as soon as possible.

🙋 What should I do if I am outside the house and the battery is completely out of power?

The door can be opened with a spare mechanical key or use a USB port at the bottom of the lock body outside the door for emergency charging.

🙋 If smart lock is malfunction, but mechanical key is inside the house?

In an emergency, if the customer fails to provide the mechanical key and the technician can only unlock it by sabotage, an unlocking fee will be charged. In addition, the company will not be liable for any damage to the product.

🙋 In case of Wifi configuration failure?

Please check the Wifi password and ensure that the Wifi connected to the device is 2.4G spectrum, and it is recommended that the distance between the device, mobile phone, and router be within 1 meter.

🙋 How to reserve installation service?

Fill in Online enquiry form

or Fill in Panasonic Smart Lock installation form and fax to：2408 0316

or Contact customer service hotlines：2406 5666

🙋 What are the precautions for the laser void label on the packaging box?

For security reasons, the laser void label on the packaging box must be opened in front of the installation technican; if the customer tears the void label by himself/herself, the company will not be liable for any loss or damage to the product.

Please keep the purchase invoice and the warranty card properly

* The product is subject to the actual product. Photos and product shots are for reference only. The actual color and size may vary slightly from those shown.

* Product specifications are subject to change without prior notice.
