23BWDBH

Window Mount – Thermo Ventilator (Advance Type)

Window Mount Installation
Easy installation with small installation size
Maximum Power Consumption: 1,400W
Ventilation Speed up to 220m3/h
New RF IPX4 Remote Control with magnetic base
Ventilation / Heating / Dry Hot (Clothes Drying) / Dry Cool (Circulation) Feature
Auto/ Manual Swing Operation

Color: Pearl White

Price: HK$3,380

Feature
Specifications
FAQ
Recipe

User Manual
Catalogue
Downloads:

Feature

Window Mount Installation
Duct Installation is not required

Maximum Power Consumption: 1,400W
Ventilation Speed up to 220m3/h
New RF IPX4 Remote Control with magnetic base(Need to pair with the product before use)

Smaller installation size with dimension of 242 x 238mm (H x W)
Louver Size (mm): 280 (H) x 280 (W)
Size(mm) : 280 (W) x 280 (H) x 286 (D)

Pre-set Timer Control Feature
Ventilation / Heating / Dry Hot (Clothes Drying) / Dry Cool (Circulation) Feature
Auto/ Manual Swing Operation
Antibacterial Filter
Max. Time
- Heat: 180 mins
- Vent. CONT.
- Dry Hot: 360 mins
- Dry Cool: CONT.

Specifications

		23BWDBH

		23BWDBH
Net Weight		4.7 Kg
Wattage	Ventilation	34 W
Wattage	Max. Wattage	1,400 W
Air Volume	Ventilation	220 CMH
Noise Level	Ventilation	48 dB
Noise Level	Heating	48 dB
Heater		PTC
Control Type		Wireless Remote
Heating		Yes
Dry		Hot‧Cool
Ventilation		Yes
Timer		15/30/60/180/360 (Minute)
Filter		Antibacterial Filter
No. of Motor / Blade		1 / 1
No. of Exhaust Outlet		1
Installation Hole Size		238 x 242 mm 9.37 x 9.53 inch (W x H)

FAQ

🙋 Installation hole size and louver size

Model	Type	Installation hole size Height x Width (mm)	Louver size Height x Width (mm)
23BWAH	Window Mount	242 x 238	280 x 280
23BWBH	Window Mount	242 x 238	280 x 280
23BWDBH	Window Mount	242 x 238	280 x 280
30BWBH	Window Mount	300 x 275	350 x 320
30BGCH	Ceiling Mount	300 x 300	360 x 360
40BECH	Ceiling Mount	280 x 400	350 x 472
40BLAH	Ceiling Mount	280 x 400	350 x 472

* The product is subject to the actual product. Photos and product shots are for reference only. The actual color and size may vary slightly from those shown.

* Product specifications are subject to change without prior notice.
